32 RAID Configuration
StorCase Technology, Inc. InfoStation 5-Bay RAID User's Guide - Rev. C00
Figure 12: Advanced Configuration Wizard
(Actual screen may vary)
Advanced Configuration
The Basic Configuration Wizard provides six (6) predefined storage policies (page 23) to
quickly configure the InfoStation. Each predefined policy allocates the maximum system
capacity to the selected policy.
The Advanced Configuration Wizard (Figure 12) however, allows the user to configure up to
ten (10) volumes, each with different storage policies and capacities. This flexibility provides
numerous combinations of performance, redundancy, and capacity to custom meet unique
business requirements.
Storage
Policy
Volume
List
Drive
Graph
Advanced
Controls
WIZARD
• Storage Policy Identifies available storage policies for assignment.
• Volume List Shows Volume, Mode (Policy), and Size details for created vol-
umes. The "Total GBs Left" field shows the remaining capaci-
ty (in GB) for all drives.
