Typical sata configurations – StorCase Technology InfoStation 5-Bay SATA 3Gbps RAID User Manual
Page 29
InfoStation 5-Bay RAID User's Guide - Rev. C00
StorCase Technology, Inc.
Installation
19
TYPICAL SATA CONFIGURATIONS
NOTES:
The installation, configuration, and use of the StorCase InfoStation chassis
requires a certain level of expertise and experience on the part of the user/
integrator. Since there are many configuration options and variables (ie. host
platforms, applications, etc), only general/typical configuration guidelines will
be discussed in this User's Guide.
The InfoStation 5-Bay HBA has four (4) SATA ports, each designed to operate
independently of each other via the RAID Manager software.
2m external cable is provided with the InfoStation.
Figure 8A: Typical SATA Host Connection to InfoStation
To Host
(with SATA
or eSATA
connection)
2m External SATA Cable
(Provided)
InfoStation Rear
