Introduction

StorCase Technology, Inc.

InfoStation 5-Bay RAID User's Guide - Rev. C00

Front Panel

(Figure 2)

•

SCA Drive Carrier(s) - Accommodate up to five (5) 3.5" SATA 3Gbps devices.
Backplane design with direct-connect SCA connectors eliminates cable connections
to SATAII drives, increases data integrity, and supports drive hot swappability.

•

Drive Bay LED(s) - Provide the following information:

Drive Ready -

Indicates that the drive is properly installed and ready for

(BLUE)

access.

Drive Activity -

Indicates that the drive is being accessed.

(YELLOW)

Drive Fault -

Indicates a drive failure.

(RED)

•

Chassis LED(s) - Provide the following information:

Fan Fault -

Indicates fan fault.

(RED)

Rebuild -

Indicates array being rebuilt.

(RED)

OverTemp -

Indicates overtempurature condition (over 50

C).

(RED)

System Fault -

Indicates system fault.

(RED)

Power -

Steady glow indicates chassis power is ON

(GREEN)
