StorCase Technology, Inc. DE200i-SW/SWC User's Guide - Rev. C01
14 Installation
NOTE: The lock on the DE200 receiving frame functions as a lock and a DC power
switch for the carrier unit. The lock must be engaged (turned counterclock-
wise) in order to supply power to the carrier and installed drive unit.
6. The new drive may need to be formatted or initialized prior to use with the operating
system and applications software. Refer to the drive and/or computer manufacturer's
documentation for formatting information.
Table 2: 16-Bit Wide Single-Ended Unit ID Display
DISPLAY
(HEX)
UNIT
NUMBER (
10
)
DISPLAY
(HEX)
UNIT
NUMBER (
10
)
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0147
Figure 10: Unit ID Select Switch Location
