DE200i-S User's Guide - Rev. D01 StorCase Technology, Inc.
Appendix B - Factory-Installed Options 21
3. As the unit ID number flashes, the Hot Swap Board monitors the activity of the SCSI
bus. When activity is no longer present, the Hot Swap Board will remove power from
the drive and then remove the device from the SCSI Bus. The unit ID number will continue
to flash during this period.
4. After a short length of time the unit display will turn from a flashing unit ID number to
a steady “u”, indicating that the device is powered down, unlocked and ready to be
removed from the receiving frame.
Carrier Installation
Follow the procedures below to install the DE200i-S Carrier into the receiving frame equipped
with the Hot Swap option.
1. Install the carrier into the Receiving Frame. A "u" will be present on the front panel,
indicating that the carrier is in an unlocked condition.
2. Turn the key lock mechanism, located on the front of the receiving frame, counter
clockwise to the ON position. This locks the drive into the receiving frame and activates
the Hot Swap Board. The drive will begin to spin up and the unit number on the display
will begin flashing.
3. After a short length of time the unit display will stop flashing, indicating that the device
is ready to be used.
