StorCase Technology DE200i-S - Manual (Page 23)

StorCase Technology, Inc. DE200i-S User's Guide - Rev. D01
16 Appendix A - Specifications/Dimensions
Chassis Reliability/Maintainability
MTBF
500,000 Hours
MTTR 5 Minutes
Preventive
Maintenance
None
Electrical Specifications
Input
+5V 65mA
+12V 400µA
Environmental Specifications
Operating Storage
Ambient Temperature 0° C to 40° C -40° C to 70° C
Relative Humidity (1) 10% to 80% 10% to 90%
Altitude -1000 to 10,000 ft -1000 to 40,000 ft
-305m to 3048m -305m to 12195m
Shock (2) 10g 60g
(1) Non-condensing with maximum gradient of 10% per hour.
(2) 11 msec pulse width 1/2 sine wave.
Physical
Specifications
Carrier Receiving Frame
Height 1.68" (42.7mm) 1.70" (43.2mm)
Width 5.14" (130.6mm) 5.75" (146.1mm)
Depth 7.38" (187.5mm) 8.18" (207.8mm)
Weight 1.2lb. (0.55kg) 1.3lb (0.59kg) (1)
(1) Plus weight of installed disk drive.
(2) With carrier removed.
Appendix A - Specifications/Dimensions
SCSI Data Express subsystems conform to the Small Computer Systems Interface (SCSI)
Standard set by the American National Standards Institute (ANSI).
