DE200i-S User's Guide - Rev. D01 StorCase Technology, Inc.
Introduction 3
0484
Drive Carrier
Receiving
Frame
Figure 2: DE200i-S Receiving Frame and Carrier
This User's Guide describes the steps required to install the StorCase Data Express
DE200i-S removable enclosure inside a computer peripheral bay or external expansion
chassis. This guide supplements documentation provided with the host computer system,
operating system, and the drive to be installed within the Data Express carrier.
General Description
The StorCase Technology Data Express ® DE200i-S is a removable drive carrier and receiving
frame designed to provide durable and reliable mounting for one (1) 3.5” SCSI drive within a
5.25" half-height peripheral slot (Figure 2).
The DE200i-S allows a drive to be removed and transported to another DE200i-S-equipped
computer or expansion chassis, and also provides the ability to secure sensitive data by
removing and storing the drive safely for future use.
The DE200i-S (Figure 2) was specifically designed for use in high shock and vibration
environments (e.g. aircraft) which may also have non-PVC material requirements. The DE200i-
S is equipped with manual lock down thumbscrews to secure the drive carrier within its receiving
frame, and a drive lock/power switch with a fixed key which can be reconfigured by the user
to be removable, if desired. The DE200i-S uses teflon ID select and power cables, and halogen-
free I/O cables.
