Configuration
-
TTL provides an edit box for entering a time-to-live registration period in seconds
-
Security type is a combo box with types of logon credentials encryption:
o
H323Alias – login and password are transmitted unencrypted as plain text
o
CRYPTO-TOKEN – encrypt the logon credentials using the MD5 algorithm
o
CHAP – CHAP encryption of data
-
Endpoint type is a combo box used to define how the DVX-7090 Router will register to
the remote registrar/gatekeeper, as a terminal or as a gateway
4.3.4 G ATEWAY NAT-, FAX - RELATED AND TYPE - OF - SIGNALING PROPERTIES
The area of the form that serves to configure the gateway NAT- and fax-related options as well
as pertinent signaling protocol parameters is illustrated in Fig. 25
Note:
Actually the web interface displays either the H.323 options form or the SIP options
form in accordance with the type of signaling selected in the combo box Signaling (see Fig. 22)
Fig. 25 Gateway NAT, fax and signaling options
The gateway settings shown in Fig. 25 are identical to the similar parameters appearing on the
User configuration form. Refer to 4.2.3 for a detailed explanation of the configuration
parameters.
4.3.5 G ATEWAY CODEC CAPABILITY SETTINGS
The gateway codec capability parameters are identical to those described for the User
configuration page (see 4.2.5)
4.4 C
ONFIGURING
DVX-7090
SERVICES
To access the services page, click the tab . The page presents a table view similar to
that illustrated in Fig. 26
