SOR 1550 Top Mounted Level Switch User Manual
Page 7
Form 865 (11.13) ©SOR Inc.
7/8
Troubleshooting
Symptom
Probable Cause
Float in actuated position but no
output signal.
a. No power supply.
b. Switch damaged. (Replace.)
Float in de-actuated positon but
still receiving an output signal.
a. Switch damaged. (Replace.)
Liquid in vessel at the actuation
level but unit does not respond.
a. Leaky or collapsed float. (Replace.)
b. Liquid specific gravity too low.
c. Float stem bound up or dirty. (Clean.)
d. Float travel is obstructed. Verify float
can move freely and is not obstructed
when installed.
Part Number
Description
3130-091
W9 - SPST Hermetically Sealed Switch Capsule
3130-245
W1 - SPDT Hermetically Sealed Switch Capsule
3130-259
W1 - SPDT Switch/Conduit Connection Assembly (CK Option Only)
3130-107
L9 - SPST Hermetically Sealed Switch Capsule
3130-244
L1 - SPDT Hermetically Sealed Switch Capsule
3130-260
L1 - SPDT Switch/Conduit Connection Assembly (CK Option Only)
3101-122
316SS Float. (Consult factory for other materials.)
3130-396
Actuator Arm Replacement Kit
Replacement Parts
