2/4

Form 466 (05.13) ©SOR Inc.

Process Connection

Securely connect the process line to the pressure port using two wrenches: one to hold the
hexagonal flats on the pressure port, the other to tighten the process pipe or tube fitting.

Ensure that the process connection is tightened and positioned so that
any binding and torsional forces imposed on the pressure switch are
minimal. Do not loosen the pressure port from the body because leakage
could result or the pressure switch could be rendered inoperative.

Electrical Connection

Ensure that wiring conforms to all applicable local and national electrical codes and install
unit(s) according to relevant national and local safety codes.

V1 – Weathertight

SPDT: Screw terminal block with marked insulation.

Common

Normally Open

Normally Closed

C1

NO1

NC1

V3 – Explosion proof

DPDT (2-SPDT): Hermetically sealed switching element

capsule has 18” - 18 AWG wire leads color coded and marked.

Common

Normally Open

Normally Closed

C1 - Blue

NO1 - Black

NC1 - Red

C2 - Yellow

NO2 - Brown

NC2 - Orange

GR - Ground (earth) green wire connected to each hermetically sealed switching element capsule.

Calibration

Remove the housing cover.

Connect a suitable variable pressure source with a calibrated reference gauge to the

pressure port. Connect an ohmmeter or test lamp across the switching element contact

terminals to monitor contact continuity. Use a 3/4” open-end wrench to turn the

adjusting

nuts.

Slowly increase pressure to the pressure port. The continuity tester will indicate that

the contacts have changed state when increasing set point is reached. Note pressure

at increasing set point. If increasing set point is too low, turn the left adjusting nut

clockwise to raise the increasing set point. If increasing set point is too high, turn the

left adjusting nut counterclockwise to lower the increasing set point.

Safety Integrity Level (SIL) Installation Requirements

The SOR pressure switches have been evaluated as Type-A safety related hardware.
To meet the necessary installation requirements for the SIL system, the following
information must be utilized:

„ Proof Test Interval shall be one year.
„ Units may only be installed for use in Low Demand Mode.
„ Products have a HFT (Hardware Fault Tolerance) of 0, and were evaluated in a

1oo1 (one out of one) configuration.

Form 1538 (03.12) ©2012 SOR Inc.
