6 © 2 0 0 3 d i r e c t e d e l e c t r o n i c s , i n c .
rre ella ayy h ha arrn ne essss ((H H2 2)),,
6 6--p piin n c co on nn ne ec ctto orr
*note: VIOLET and VIOLET/BLACK are common at
the fuse holder.
H H2 2//1 1
H H2 2//2 2
H H2 2//3 3
H H2 2//4 4
H H2 2//5 5
H H2 2//6 6
WHITE/BLACK Lock #87A Normally Closed
GREEN/BLACK Lock #30 Common–Output
VIOLET/BLACK* Lock #87A Normally Open–Input
BROWN/BLACK Unlock #87A Normally Closed
BLUE/BLACK Unlock #30 Common–Output
VIOLET Unlock #87 Normally Open–Input
