Rocktron Replifex User Manual
Page 8

5
Front Panel DescriptionOperating the Replifex
™
Operating the Replifex
™
1 3
INPUT LEVEL control
This control adjusts the unit’s gain to match the signal level at the
input of the Replifex
™
. Use the INPUT LEVEL meter to determine
the setting of this control.
1 4
OUTPUT LEVEL control and CLIP LED
This control is used to adjust the overall output level of the unit.
The CLIP L.E.D. is part of the output section and, when lit, indicates
that the final analog output is being overdriven due to the Effects
Level, Direct Level and Output Level being set too high. If this
should occur, reduce these levels until the L.E.D. does not light.
1 5
REFERENCE LEVEL switch
This switch adjusts the output range of the unit and may be set at
either -10dB or +4dB. When using the Replifex
™
with professional
studio equipment providing a nominal input level of +4dB, it is
recommended that the +4 setting is used for best results. If the
Replifex
™
is to be connected to a high sensistivity input, such as the
input to a guitar amp, the -10 setting should be used.
