Banshee talkbox – Rocktron Utopia G200B w/Banshee User Manual

Page 44

The Banshee Talkbox is a self-contained talkbox effect with its own pr eamp and power amplifier

for driving the internal horn driver. Unlike other Banshee Talkboxes in the Rocktron product range, the

Utopia G200B talkbox makes use of the internal presets of the G200B. Different distortions and effects

can be used with the talkbox to create new and different tones and sounds.

The Banshee has three controls and a switch that allow you have many different combinations of

sounds depending on your need.

The Banshee Talkbox controls and their functions are as follows:

This control determines the overall gain of the internal preamp. This will

add that "talkbox" edge to the preset you have selected.

Thie control determines the overall TONE or equaliztion of the talkbox

sound.

LEFT/MONO output knob = Determines the amount of attenuation that

may be applied to the LEFT/MONO output signal sent to your amplifier

when using the Banshee and your amplifier's live sound together at the

same time.

Using the LEFT/MONO output control provides added flexibility with

regards to customizing the blend you hear on stage between your amps

stage volume and the Banshee's physical output volume when both are

desired.

Turning the LEFT/MONO output knob CCW reduces your amplifiers stage

volume. Turning the LEFT/MONO output control FULL CW brings you

back to the original LEFT/MONO output level.

Note: The LEFT/MONO output control only has an effect on the LEFT/

MONO output signal when he BANSHEE is in use. When the Banshee

is disengaged the LEFT/MONO output control will be bypassed and the

LEFT/MONO output will return to its normal state.

LEFT/MONO Mute switch = Determines whether the LEFT/MONO output

sent to your amplifier is ON or OFF only when the Banshee is being used.

This switch allows you to turn "ON" and "OFF" the Banshee Talkbox at

any time. The LED above the switch will be "LIT" when the Talkbox is

"ON"

GAIN

TONE

LEFT/MONO

OUTPUT

LEFT/MONO

MUTE

SWITCH

"BANSHEE"

SWITCH

6. BANSHEE TALKBOX
