6. FLANGER Function
The FLAN GER function is available if y ou have selected it in the MODULATION EFX Function.
Flanging involves splitting the input signal into at least two ind ivid ual d elay ed signals (Voice 1 and
voice 2), then modulating these delayed signals so that, when summed back with the direct signal, phase
cancellations will occur at some frequencies while peaks in the response will occur at others.
The PARAMETER SELECT knob will allow you to access these FLANGER parameters:
The Flanger IN/OUT parameter determines whether the Flanger is active for the
current preset.
The LEVEL 1 par ameter d eter mines the volume of Voice 1 r elative to Voice 2.
Tip: Keep the settings of these levels high and use the
DIR/EFF mix parameter in the Mixer function to con-
trol the overall amount of flanged signal.
The PAN 1 par ameter allows y ou to pan Voice 1 to the left or r ight
channel.
The DEPTH 1 par ameter ad justs the amount of mod ulation of Voice 1 . Lower
DEPTH settings produce more subtle effects, while higher settings will result in
a more drastic effect.
The R ATE 1 par ameter d eter mines the speed at which Voice 1 is mod ulated .
The LEVEL 2 par ameter d eter mines the volume of Voice 2 r elative to Voice 1.
The PAN 2 par ameter allows y ou to pan Voice 2 to the left or r ight
channel.
The DEPTH 2 par ameter ad justs the amount of mod ulation of Voice 2. Lower
DEPTH settings produce more subtle effects, while higher settings will result in
a more drastic effect.
The R ATE 2 par ameter d eter mines the speed at which Voice 2 is mod ulated .
The REGENERATION parameter determines how much of the delayed out-
put signal is fed back into the input. More regeneration produces a more pro-
nounced "jet air plane" ty pe of effect.
FLANGER
LEVEL 1
PAN 1
DEPTH 1
RATE 1
LEVEL 2
PAN 2
DEPTH 2
RATE 2
REGEN
