The DriveRack® PX has been carefully designed and engineered to ensure that all aspects of
operation are intuitive and logical. Simply stated, the DriveRack® PX operating system was
designed with the user’s best interest in mind.
3.1 Basic Navigation Modes
Navigational aspects of the DriveRack® PX are clear, concise and more important: flexible.
The DriveRack® PX provides you with essentially three different modes of navigation when
performing preset edits. 1. EDIT buttons - This array of 5 edit buttons is your primary mode
of directly accessing any signal processing module. 2. NEXT PG & PREV PG page buttons -
Successive presses of the NEXT PG or PREV PG page buttons will move the user from one page
to the next in a signal processing editor. 3. Data Wheel - The Data Wheel is used to move
through the preset menu of the DriveRack® PX. The Data wheel is also used to change the
values of the selected parameter by simply rotating the wheel. Pressing the Data wheel will
toggle between the available parameters on any selected page of the currently selected editor.
3.2 Button Array Overview
SETUP
AFS
RECALL
SUBHARMONIC COMP/LIMITER
UTILITY
PRESET
NEXT PG
STORE
EQ
WIZARD UTILITY
PREV PG
WIZARD
PREVIOUS PAGE - Moves to the previous page in the currently selected
menu.
SETUP
AFS
RECALL
SUBHARMONIC COMP/LIMITER
UTILITY
PRESET
NEXT PG
STORE
EQ
WIZARD UTILITY
PREV PG
WIZARD
NEXT PAGE - Moves to the next page in the currently selected menu.
SETUP
AFS
RECALL
SUBHARMONIC COMP/LIMITER
UTILITY
PRESET
NEXT PG
STORE
EQ
WIZARD UTILITY
PREV PG
WIZARD
SETUP - Press and release to enter the high-pass and bandpass filter
editor. Press and hold to enter the first page of the Powered Speaker Setup
Wizard.
SETUP
AFS
RECALL
SUBHARMONIC COMP/LIMITER
UTILITY
PRESET
NEXT PG
STORE
EQ
WIZARD UTILITY
PREV PG
WIZARD
SUBHARMONIC - Selects the Subharmonic Synthesizer editor.
SETUP
AFS
RECALL
SUBHARMONIC COMP/LIMITER
UTILITY
PRESET
NEXT PG
STORE
EQ
WIZARD UTILITY
PREV PG
WIZARD
COMP/LIMITER - Press to cycle through the compressor editor and output
limiter editors.
SETUP
AFS
RECALL
SUBHARMONIC COMP/LIMITER
UTILITY
PRESET
NEXT PG
STORE
EQ
WIZARD UTILITY
PREV PG
WIZARD
EQ - Press and release to cycle through the graphic EQ and parametric EQ
editors. Press and hold to enter the first page of the Auto-EQ Wizard
SETUP
AFS
RECALL
SUBHARMONIC COMP/LIMITER
UTILITY
PRESET
NEXT PG
STORE
EQ
WIZARD UTILITY
PREV PG
WIZARD
PRESET/RECALL - Press and release to return to the preset view, showing
preset number, preset bank (user or factory), preset name, and signal path.
Press and hold to activate the [RECALL] button function which provides for
selection and loading of a new preset.
DriveRack
®
PX
Section 3
Editing Functions
®
Section 3 - Editing Functions
