Mighty Mule FM350 - Manual (Page 33)

29 rev 07.16.12
1 2 3 4 5 7 6
Photo Beams
(R4222)
Push Button Control
Automatic Gate Lock
(FM143)
Vehicle Sensor (FM138)
Edge Sensor
NOTE: Connections are for typical applications.
For additional connection options not illustrated here
refer to the accessory manual for details.
2
1
1
4
1
1 Keypad
(FM137)
5
1
2
1 2 ABC 3 DEF
4
GHI
5
JKL
6
MNO
7
PRS
8 TUV 9 WXY
0
3
RED BL
A
CK
CHARGING
POWER
RCVR
GRN BLK RED EXIT
SAFETY
EDGE
CY
CLE
COMMON
LINK
AUX
OUT
SOLAR
INPUT
18VAC/ H L
(+12 v)
(See additional wiring digram on pg. 30)
(+12 v)
( – )
( – )
WIRING ACCESSORIES
DIP switch 4 set to
OFF position (Default)
