ALPHA 1-4 LSC&
ALPHA 2-4 LSC&
10 Technical data
Version 01/2011, Rev. 1.5 of 16/12/2013 • sb
87
Translation of the original operating manual
Connection requirements
(without vacuum pump and
accessories)
Alpha 1-4 LSC
plus
Alpha 2-4 LSC
plus
Electrical connection: 1 x 230V / 50-60 Hz 1 x 230V / 50-60 Hz
Protection class: I I
IP protection category according to
DIN 60529: 11 11
Nominal power: 0.9 kVA 1.62 kVA
Nominal current: 4.0 A 7.0 A
Mains fuse: 10 A F 12 A F
Pressure control valve connection: 230 V, 50/60 Hz, 20 VA max. 230 V, 50/60 Hz, 20 VA max.
Vacuum pump connection: 230 V, 50/60 Hz, 2 A max. 230 V, 50/60 Hz, 2 A max.
Filling quantity Alpha 1-4 LSC
plus
Alpha 2-4 LSC
plus
Refrigerant: See name plate See name plate
Physical data (without vacuum
pump and accessories) Alpha 1-4 LSC
plus
Alpha 2-4 LSC
plus
Dimensions
- height:
- width:
- depth:
415 mm
390 mm
555 mm
(incl. vacuum flange connection)
415 mm
390 mm
555 mm
(incl. vacuum flange connection)
Weight: approx. 48 kg approx. 60 kg
Noise level
according to DIN 45635:
54 dB(A)
54 dB(A)
EMC according to EN 55011: Class B Class B
Heat emission: 0.6 kW min.
1.1 kW max. 1.1 kW min.
1.6 kW max.
Equipment connections Alpha 1-4 LSC
plus
Alpha 2-4 LSC
plus
Vacuum connection: Small flange connection DN25KF
(ISO 28403, DIN 2861) Small flange connection DN25KF
(ISO 28403, DIN 2861)
Media drain valve: Hose nozzle DN10
(outside diameter 12 mm) Hose nozzle DN10
(outside diameter 12 mm)
Aeration valve: Hose nozzle DN6
(outside diameter 10 mm max.)
Hose nozzle DN6
(outside diameter 10 mm max.)
Vacuum sensor: SUB D-9
VSP 62 SUB D-9
VSP 62
Data interface (LAN): RJ 45 RJ 45
