67. Cut the airbox along your marked lines.
After the final cuts have been made, your new
airbox should look like this.
68. Re-install your air filter housing, make sure
to plug in the MAF sensor after bolting down the
housing bolts.
NOTE: LPE recommends the use of a K&N air
filter (part # 33-2411).
69. Lift up on the front of the supercharger
and remove the wood block or wedge that
was inserted earlier. Line up the supercharger
bolt holes with the corresponding holes in the
cylinder heads and insert the ten (10) bolts that
secure it.
70. Tighten the bolts down in the order shown,
using an 8 mm socket make a first pass of
44 lb-in (4 Nm). Then make a final pass in
sequence to 89 lb-in (10 Nm).
NOTE: Use caution when removing and
installing cover and supercharger bolts. They
have plastic Isolators in the bolt holes that can
fall out. Isolators must be re-used.
