REPLACEMENT PARTS
44
Ref.
No.
Qty. Catalog No. Description
1 1 5066600 Glass Viewing Window
2 1 5066700 Polycarbonate Lexan Viewing Window
3 1 5067200 Window Gasket – not shown – For models with fiberglass liner
3A 1 5098400 Window Gasket – not shown – For models with stainless steel liner
4 1 5005500 Kit: 8-1/2 Size Neoprene Gloves (1 pr) O-Rings (2)
5 1 Pr 1640500 8-1/2 Size Neoprene Gloves
6 1 5005501 Kit: 8-1/2 Size Butyl Gloves (1 pr), O-Rings (2)
7 1 Pr 1640501 8-1/2 Size Butyl Gloves
8 1 5005502 Kit: 8-1/2 Size Hypalon Gloves (1 pr), O-Rings (2)
9 1 Pr 1640502 8-1/2 Size Hypalon Gloves
10 1 5005600 Kit: 9-3/4 Neoprene Gloves (1), O-Rings (2)
11 1 Pr 1640600 9-3/4 Size Neoprene Gloves
12 1 5005601 Kit: 9-3/4 Size Butyl Gloves (1 pr), O-Rings (2)
13 1 Pr 1640601 9-3/4 Size Butyl Gloves (1 Pr)
14 1 5005602 Kit: 9-3/4 Size Hypalon Gloves (1 Pr.), O-Rings (2)
15 1 Pr 1640602 9-3/4 Size Hypalon Glove (1 Pr)
16 1 Pr 1640000 O-Rings for Gloves
17 1 Pr 1965600 Clamps, for Gloves
18 1 1361500 Pressure Gauge, ± 5" H
2
O
19 1 1361600 Vacuum Gauge, 0-30" Hg
20 3 1361900 3/8" Valve
21 1 1361901 1/2" Valve
22 3 1329700 Switch, SPST, 115V
22A 3 1301500 Switch, DPST, 230V
23 1 1329701 Switch, SPDT, 115V
23A 1 1301501 Switch, DPDT, 230V
24 1 5064200 Transfer Chamber Door Gasket – For models with fiberglass liner
24A 1 5098300 Transfer Chamber Door Gasket – For models with stainless steel liner
25 1 1248400 External Receptacle, 115V
25A 1 1290900 External Receptacle, 230V
26 1 1327201 Circuit Breaker, 10 Amp, 115V
26A 1 1291200 Circuit Breaker, 10 Amp, 230V
27 1 1327203 Circuit Breaker, 6 Amp, 115V
28 1 5077501 Pressure Control Module – Models 5070000, 5070100, 5080000 and
5080100*
29 1 5080501 Purge/Fill Control Module – Models 5080000 and 5080100 only*
30 1 5060300 Kit, Pressure Relief Bubbler
A Glove Port Components – detailed on page 45
B Sealed Receptacle Components – detailed on page 45
C Fluorescent Lamp Assembly – detailed on page 46
D Inner Door Assembly – detailed on page 47
E Outer Door Assembly – detailed on page 48
*For solenoid valves and pressure transducer refer to Plumbing Diagrams
