Labconco XVS Ventilation Stations 4865060 User Manual
Page 54
Appendix A: Replacement Parts
Product Service 1-800-522-7658
50
Item Qty.
Part
Number
Description
7E
1
3925300
Tall Latch Bracket
7F
1
6916501
Tall Latch Sash
7G
1
3974300
Gas Spring, 5', 20#
7H
1
3974301
Gas Spring, 6', 30#
7I
1
3974302
Gas Spring, 8' 40#
7J
1
3973200
Gas Spring, 5' Tall, 30#
7K
1
3973201
Gas Spring, 6' Tall, 40#
7L
1
3973202
Gas Spring, 8' Tall, 50#
8A 1
3986500
Sash
Assembly
2'
8B 1
3986501
Sash
Assembly
3'
8C 1
3986502
Sash
Assembly
4'
8D
1
3987100
Sash Assembly Tall 2'
8E
1
3987104
Sash Assembly Tall 3'
8F
1
3987102
Sash Assembly Tall 4'
8G 1
3972300
Sash
Assembly,
5'
8H 1
3972301
Sash
Assembly,
6'
8I 1
3973202
Sash
Assembly,
8'
8J
1
3977200
Sash Assembly, 5' Tall
8K
1
3977201
Sash Assembly, 6' Tall
8L
1
3977202
Sash Assembly, 8' Tall
9A
1
3907400
Bracket, Air Foil Right
9B
1
3907401
Bracket, Air Foil Left
9C
2
1932401
Washer, Shoulder Plastic
9D
2
1912108
Washer, .194 ID x .38 OD x .03 thick plastic
9E
2
1909217
Cap Nut #10-24 SS
10A 1
3905600
Air
Foil
2'
10B 1
3905601
Air
Foil
3'
10C 1
3905602
Air
Foil
4'
10D 1
3969200
Air
Foil
5'
10E 1
3969201
Air
Foil
6'
10F 1
3969202
Air
Foil
8'
11A 1
3905300
Header
2'
11B 1
3905301
Header
3'
11C 1
3905302
Header
4'
11D 1
3905303
Header
5'
11E 1
3905304
Header
6'
11F 1
3905305
Header
8'
12
1
3913100
Cover Plate, Exhaust (Top or Bottom)
13A
1
3912400
Upper Exhaust Transition 5" Hose
13B
1
3912401
Upper Exhaust Transition 6" Duct
13C
1
3912402
Lower Exhaust Transition 5" Hose
13D
1
3912403
Lower Exhaust Transition 6" Duct
14A
1
1934601
Bushing, Heyco with Flex Shutter 1.50 dia.
14B
1
1936800
Bushing, Heyco Closed 1.50 dia.
15A 2
7868402
Spacer
Bushing
15B
2
1912108
Washer, .194 ID x .38 OD x .03 T. Plastic
15C
2
1889316
Screw, #10-24 x 1.00 PH. (SS)
16A
2
3915400
Side Air Foil, Short
16B
2
3915401
Side Air Foil, Tall
16C
4
1889912
Screw, 6-32 x .75 PH. Type F, Oval Head
17
1
1595619
Hole Plug, .500 dia. Gray
18
1
1595621
Hole Plug, 1.187 dia. Gray
19A
1
3901100
Label, Ventilation Station
19B
1
3901200
Label, Balance Enclosure
