Chapter 3: Getting Started

Product Service 1-800-522-7658

Figure 3-5

Concealed Bottom Connection to FilterMate With Outside Thimble Exhaust Connection

To Outside Exhaust Via Thimble Connection (6" nominal)

Airflow monitor moved
forward per Chapter 6.
