Chapter 2: Prerequisites
Product Service 1-800-522-7658
6
Exhaust and Blower Requirements
The exhaust connection has been designed to accept a 2" x 10" (5.1cm x
25.4cm) nominal exhaust collar. The enclosure has two possible exhaust
connections with either the top exhaust open and the bottom exhaust closed
or vise versa. The bottom exhaust connection is primarily used in
installations where the hose or ductwork needs to be concealed. Labconco
offers accessory transition adapters for the top or bottom exhaust connection
to either a 5" hose or 6" duct. See Chapter 7 for ordering any of these
accessories. For house exhaust, only one exhaust connection is required for
the 2' through 6' enclosures and two exhaust connections are required on the
8' enclosure. Data for the exhaust volume and enclosure static pressure loss
are listed for each enclosure model at face velocities of 60, 80 and 100 fpm.
When using the accessory FilterMate Portable Exhausters, it requires the 5"
Transition Adapter 3912400, which is sold with the FilterMate. Multiple
FilterMate Portable Exhausters require the airflow to be properly balanced.
The 5', 6' and 8' enclosures require two or three FilterMate Portable
Exhausters dependent on face velocity and size.
Enclosure
Width
Enclosure
Height Model
Description
Face
Velocity
(fpm)
Exhaust
Volume
(CFM)
Static Pressure
Loss (in w.g.)
Number of
Required
FilterMates
2'
22.75"
8" Sash
2' XPert/2' XVS
60
80
100
70
95
120
.02"
.03"
.05"
1
1
1
3'
22.75"
8" Sash
3' XPert/3' XVS
60
80
100
110
145
185
.04"
.06"
.10"
1
1
1
4'
22.75"
8"
4' XPert/4' XVS
60
80
100
150
200
250
.06"
.10"
.16"
1
1
1
2'
32"
10" Sash
Tall 2' XPert/2' XVS
60
80
100
90
120
150
.03"
.05"
.08"
1
1
1
3'
32"
10" Sash
Tall 3' XPert/3' XVS
60
80
100
140
185
230
.06"
.10"
.15"
1
1
1
4'
32"
10" Sash
Tall 4' XPert/4' XVS
60
80
100
185
250
310
.09"
.16"
.24"
1
1
N/A
5'
22.75"
8" Sash
5' XPert
60
80
100
190
250
315
.08"
.15"
.23"
1
1
2
6'
22.75"
8" Sash
6' XPert
60
80
100
230
305
380
.12"
.21"
.32"
1
2
2
8'
22.75"
8" Sash
8' XPert
60
80
100
310
410
510
.07"
.12"
.18"
2
2
3
5'
32"
12" Sash
Tall 5' XPert
60
80
100
290
385
480
.20”
.35"
.54"
2
2
3
6'
32"
12" Sash
Tall 6' XPert
60
80
100
350
465
580
.27"
.48"
.75"
2
3
3
8'
32"
12" Sash
Tall 8' XPert
60
80
100
465
620
775
.15"
.27”
.42"
3
3
3
