5.2.8 IrDA Window

Infrared communication occurs when microswitch 2 has not
been activated.
The following examples are types of instruments that use
infrared communications:

• Shipsurveyors

• Gascoseeker Acclaim

Fig. 5-9 IrDA Window

5.2.9 Front Panel Lock

key-lock,

as illustrated in Fig. 5-10. Two (2) keys are supplied with the
unit.

Fig. 5-10 Front Panel Lock

IrDA

COMMUNICATIONS
