Genesis™ Series 4x4 AV Matrix Switches
19
5.2.3 Settings Tab
Settings tab helps user to change IP address, enable/disable DHCP, enable/disable
password, change current password and load factory default settings if necessary.
Figure-14 Settings Tab
Name
User defined name for matrix. Name can be sixteen (16) characters including spaces
and special characters.
Location
User defined location of matrix. Location can be twenty (20) characters long including
white spaces and special characters.
IP
Displays current IP address of Matrix and if DHCP is disabled, it allows user to enter
new IP address.
Subnet
Displays current SUBNET address and allows user change it If DHCP is disabled.
Gateway
Displays current GATEWAY address and allows user change it if DHCP is disabled.
DHCP
Enables/ Disables DHCP.
Login
Enable /Disable login password.
Telnet
Enable /Disable telnet interface. See Section 6 for more details on how to use telnet
interface.
