5.3 IP Specific Serial Commands
The HSM matrix is equipped with a standard RS-232 interface, which allows the user
to assign a static IP address. Please refer section 4 to connect a PC to Matrix over an
RS-232 serial interface. Once you are connected use following commands to change
the network settings or restore the factory defaults.
5.3.1 Changing the network settings of unit
Note: All commands are case sensitive
Command:
IP
Where ip_address_value stands for the desired IP address
Success Response:
IP=
Error Response:
“Err! IP Address is not valid” or “IP address not changed”
Command:
SB
Where subnet_address_value stands for the desired subnet mask
Success Response:
SUBNET=
Error Response:
“Err! SUBNET Address is not valid”
Command:
GW
Where gateway_address_value stands for desired gateway address
Success Response:
GATEWAY=
Error Response:
“Err! GATEWAY Address is not valid”
WAIT until you see following Welcome message on Screen. It confirms that device
has done with applying settings and serial interface is ready for other commands.
“Welcome to Hall Research HSM matrix”
5.3.2 Restoring factory defaults
Command:
FD
Response:
“Applying Factory Defaults To Matrix- Please Wait For Welcome Message.”
This command loads factory defaults (for both IP interface and all routing
memory including presets). This command is available only for units that
have IP interface. With this command you don’t need to use FR command
since as part of the action it performs the FR function as well. Wait until you
see following welcome message on terminal screen.
“Welcome to Hall Research HSM matrix serial interface.
Please refer to user manual for matrix serial commands.”
Notice
User MUST enter ALL THREE Commands mentioned above with the correct values
and must get ‘success response’ for each in order to change the network settings.
The following message confirms that user has received a ‘success response’ for all
of the above commands and device is applying user settings:
“Applying settings to Matrix please wait”
If you did not receive the above message, renter ALL THREE values again
