Genesis Digital™ HDMI Matrix Switches

9

3.3 Making AV Routings or “Ties” from Front Panel

To make the unit as convenient and intuitive as possible the HSM matrix allows you to

make ties starting from the input channel’s point of view or from the output.

3.3.1 Making a tie starting from the output

This is the most natural way of making connections since each output gets its signal

from only one input.

Note that once you start making selections from the front panel, if you do not

hit any buttons for approximately 10 seconds, the system will exit this mode

without any user interaction.

First, press one of the output channel buttons. That output button will light up

and the current input routed to that output will light up.

At this point if you change your mind, and do not want to make any changes,

just hit SET. If you want to change to another output channel, use either the

up and down (▲▼) buttons to walk through other outputs ; or just select

another output channel.

To route the output to a different input than the one currently connected to,

hit the “candidate” input channel number. This does not actually make the

connection; the new input channel will be blinking. Again if you change your

mind, either hit the same blinking button (it will stop blinking), or hit another

input channel. When you are sure you have selected the input channel you

desire, hit SET.

3.3.2 Making a tie starting from the input

The procedure is similar to the above but a particular input can be routed to more than

one output.

Press one of the input channel buttons. That button will light up and ALL the

outputs routed from that input will light up.

If you want to change to another input channel, use either the up and down

(▲▼) buttons to walk through other inputs; or just select another input

channel.

To route the selected input to single or multiple outputs, press the output

buttons. Again, these new outputs are only “candidates” (will be blinking) and

will not be routed until you hit the SET button.
