EZ1000 Plus User Manual
15
3. Operator panel
3-1. FEED button
When you press the FEED button, the printer moves the label to the defined stop
position. If you are using continuous labels, pressing the FEED button will move label
stock until you release the button again. If you are using individual labels, pressing the
FEED button will move only one label. If the label does not stop at the correct position,
you need to run the auto-detection function on the label stock (see Section 3-3).
3-2. LED indicators
LED indicator Status Description
READY Green
Standby mode The printer is ready for
operation.
STATUS -
READY -
Error mode
The printer has detected an
error. (See Section 3-5. Error
alerts)
STATUS Red
3-3. Label size calibration
The printer can automatically detect and store label height.
That means the host computer does not need to transmit the label height to the printer.
1. Check that the label stock is loaded correctly.
2. Switch off the printer.
3. Switch the printer on again, keeping the FEED button pressed. When the READY LED
starts to flash red and the STATUS LED lights up orange, release the FEED button. The
printer will now measure the label stock and store the label height.
4. Once the printer has successfully measured the label stock, it will print a self-test
label.
