10 electrical connections – Glow-worm 18-30sxi Range User Manual
Page 26
26
0020008155A
EXTERNAL
CONTROL
CABLE
MAINS
CABLE
10 Electrical Connections
10.4 Electrical Connections - Testing
Carry out preliminary electrical system checks as below:
1. Test insulation resistance to earth of mains cables.
2. Test the earth continuity and short circuit of cables.
3. Test the polarity of the mains.
Diagram 10.4
CONTROL
PANEL REAR
COVER
STRAIN
RELIEF
SECURING
SCREW (3)
9808
CABLE
EXIT
12406
Diagram 10.3
11627
