Auto control gain setting
1. It‘s for servo(AIL,ELE,THR,RUD) control movement Gain, Set Range:0-99.
2. Min:0, equivalent shut down auto balance function. Max:99.
 If the pitch, roll and orientation rapid shaking, or flight speed increases appear
sloshing, you need reduce corresponding control channel gain; If recover to balance
is too slow, the poor control ability is require you to increase control gain.
 General condition,we just suggest you use the default parameters(50).Please do
not set control gain to a very large number at your first flight.
 After you input your settings do not forget to click in ―Set‖ button.
Throttle
Push throttle from light to strong, if the remote control steering gear chart (-100 to 100) is
set in the rudder reverse Settings throttle reverse option not to choose, if from big to small
(100 to -100) set in the rudder reverse settings the throttle reverse option, select reverse.
The general ESC throttle control (ESC) use the default settings (NOR), without ESC
reverse set.
Cruising Speed Setting
During Navigation Mode (autonomous flight) the FY-41AP will control its cruising
speed via throttle control. This speed follows the Cruising Speed Setting.
By default, the Cruising Speed Setting is 60 km/h.
You can adjust this cruising speed as per your model‘s requirement. Fly the plane in at
speeds most comfortable for cruising and Set that value via the Setting Software.
