Single-Ended Dispersion Analyzer 83
A Technical Specifications
I
MPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
Temperature
Operating 0 °C to 50 °C (32 °F to 122 °F)
Storage —40 °C to 70 °C (—40 °F to 158 °F)
Relative humidity 0 % to 93 % non-condensing
Size (H x W x D) 96 mm x 50 mm x 281 mm (3 3 / 4 in x 2 in x 11 in)
Weight 1.3 kg (2.8 lb)
SPECIFICATIONS
a
Measured wavelength range (nm) 1475 to 1626
Maximum measurement distance (km) *120 (140 with refl ector)
Distance uncertainty (km) ±(0.01 + 1 % x distance)
Chromatic dispersion b
Number of test points 8
CD uncertainty (ps/nm) ±10
Test time (s) 40
PMD c
PMD display range (ps) up to 50
PMD range (strong mode coupling) (ps) 0.1 to 20
PMD uncertainty (strong mode coupling) (ps) d ± (0.2 + 5 % x PMD)
Test time (s) <180
GENERAL SPECIFICATIONS
21 CFR 1040.10 and IEC 60825-1:2007
CLASS 1 LASER PRODUCT
SAFETY
Notes
a. Typical.
b. At 1550 nm, on 100 km of G.652 single-mode fi ber.
c. For a fi ber length Ӌ100 m.
d. For strong mode coupling PMD (telecom fi ber) up to 15 ps, with averaging.
