Setting Up the Single-Ended Dispersion Analyzer
30 FTB-5700
Defining the Automatic Fiber Name Format
Defining the Automatic Fiber Name Format
Each time you make a new acquisition, the fiber name changes
automatically according to a pattern you will have previously defined. This
name corresponds to the concatenation of a static part (prefix) and a
variable part that will be incremented.
To define the fiber name format:
1. From the main window, select the Fiber Test tab.
2. Under Information, set the various parameters according to your
needs.
Note: The fiber name, cable ID and automated additions to the file name such as
the date can be set in the Preferences tab of the Setup window. See Setting
Test Preferences on page 37 for details.
Name of the cable containing the fiber
Threshold for your fibers
Name for the fiber
Incremental suffix for the fiber
(reverts to 001 once it reaches 999)
