EXFO FTB-5700 Single Ended Dispersion Analyzer for FTB-200 v2 User Manual
Page 19
Getting Started with the Single-Ended Dispersion Analyzer
Single-Ended Dispersion Analyzer
13
Inserting and Removing Test Modules
To remove a module from the FTB-200 v2 Compact Modular
Platform:
1. Turn off your unit.
2. Position the unit so that the bottom panel is facing you.
3. Using a coin, turn the retaining screw counterclockwise until it stops.
The module will be slowly released from the slot.
4. Place the unit so that the top panel is facing you.
Turn retaining screws
clockwise
Bottom panel
