EXFO FTB-5700 Single Ended Dispersion Analyzer for FTB-200 v2 User Manual
Page 18
Getting Started with the Single-Ended Dispersion Analyzer
12
FTB-5700
Inserting and Removing Test Modules
7. While applying slight pressure to the module, use a coin to turn the
retaining screw clockwise until it is tightened.
This will secure the module into its “seated” position.
When you turn on the unit, the startup sequence will automatically detect
the module.
Turn retaining screws
clockwise
Bottom panel
