Single-Ended Dispersion Analyzer
45
6
Managing Results
Your FTB-5700 Single-Ended Dispersion Analyzer allows you to work with
two types of results:
³
Newly acquired results
³
Results loaded from existing files
To view and analyze your results, the application provides:
³
A graph and a table presenting details for a specific acquisition in the
case of chromatic dispersion
³
A window giving you an overview of all the available acquisitions, plus
the related details
It also offers customizing, saving, export and printing features based on
these results.
I
MPORTANT
Your FTB-5700 Single-Ended Dispersion Analyzer was designed to
automatically determine the length of your fiber and test
accordingly. If the test is still performed and the length indicated is
not appropriate, this mean that a strong reflective event is present
on the fiber before the non-reflective termination.
If such a situation occurs, clean the fiber end or add a reflector at
the end of the fiber to improve your results.
