LED Indicators 1 - 9
Quick Start Guide
1
LED Indicators
The LED indicators on the computer display helpful
information about the current status of the computer.
Table 1 - 2 - Front Left LED Indicators
Table 1 - 3 - Top Case LED Indicators
Some LED indicators also act as hot key buttons (see over) .
Icon Color Description
Orange DC Power is Plugged In
Green The Computer is On
Blinking Green
The Computer is in Sleep
Mode
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking Orange
The Battery Has Reached
Critically Low Power Status
Green Number Lock Activated
Green Caps Lock Activated
Green
Scroll Lock Activated (to
activate press Fn & Scr Lk)
Icon Color Description
Green UMA Mode Activated
Orange Optimus Mode Activated
Green Intel Integrated GPU (iGPU) Activated
Orange NVIDIA Discrete GPU (dGPU) Activated
White
The (optional) Bluetooth Module is
Powered On
White Hard Disk Activity
White
The (optional) Wireless LAN Module is
Powered On (see over)
White Volume Mute is Enabled (see over)
White
The (optional) PC Camera is Powered
On (see over)
White The Computer is Powered On
