Intel Video Driver Controls
HDMI Audio Configuration B - 7
B
HDMI Audio Configuration
As HDMI (High-Definition Multimedia Interface) carries both audio and video sig-
nals you will need to configure the audio output as per the instructions below.
Windows Audio Setup for HDMI
1. Connect a device with HDMI support to the HDMI-Out port.
2. Click Start, and click Control Panel (or point to Settings and click Control Panel).
3. Click Sound (Hardware and Sound).
4. Click Playback (tab), and click to select HDMI Device.
5. Click Set Default (button).
6. Click OK to close the Sound control panel.
Figure B - 6
HDMI Device
Click the taskbar volume in-
dicator
when HDMI De-
vice is selected, and you will
note that the icon at the top
of the volume level indicator
has changed.
