System Map: Bottom View
Figure 7 - Bottom View
1. Battery
2. Battery Release Latch
3. Optical Device Release Latch
4. Hard Disk Bay Cover
5. Vent
6. Sub Woofer
7. Component Bay Cover
8. Speakers
1
2
4
3
CPU
The CPU is not a user serviceable part. Opening this com-
partment, or accessing the CPU in any way, may violate
your warranty.
Battery Information
Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at
least once every 30 days or after about 20 partial discharges.
5
7
5 5
5
5
5
5
6
5
8 8
