System Map: Top View with LCD Panel Open
Figure 2 - Top View with LCD Panel Open
2
5
3
4
1
7
4
8
1. Optional Built-In
PC Camera
2. LCD
3. LED Power &
Communication
Indicators
4. Speakers
5. AP-Key Buttons &
Power Button
6. Built-In Microphone
7. LED Status Indicators
8. Keyboard
9. TouchPad and Buttons
10. Consumer Infrared
Transceiver*
* Enabled with Optional Mini-
PCI TV Tuner Only
Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft is
usually prohibited. Make
sure the module(s) are
OFF if you are using the
computer aboard aircraft.
The key combination Fn +
F11 toggles power to the
WLAN module, and the
AP-Key button
to the
Bluetooth module.
LCD Angle
When raising the LCD DO
NOT FORCE it in excess
of angle of 120 degrees.
9
6
10
7
5
