Eurocom Panther 5 - Manual (Page 41)

36
English
Pointing Device
Built-in TouchPad (scrolling key functional-
ity integrated)
Communication
Built-In Giga Base-TX Ethernet LAN
2.0M Pixel FHD USB PC Camera Module
(Factory Option) 2.0M Pixel USB PC Cam-
era Module
(Factory Option) Bluetooth 2.1 + EDR
(Enhanced Data Rate) Module
WLAN/ Bluetooth Half Mini-Card
Modules:
(Factory Option) Intel® Centrino® Ulti-
mate-N 6300 Wireless LAN (802.11a/g/n)
(Factory Option) Intel® Centrino®
Advanced-N 6230 Wireless LAN (802.11a/g/
n) + Bluetooth 3.0
(Factory Option) Wireless LAN (802.11b/g/
n) + Bluetooth 3.0
(Factory Option) Wireless LAN (802.11b/g/
n)
Card Reader
Embedded Multi-In-1 Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/
SDXC
MS (Memory Stick) / MS Pro / MS Duo
Slots
One ExpressCard (54/34) Slot
One Mini Card Slot for WLAN Module or
WLAN and Bluetooth Combo Module
Interface
Three USB 3.0 Ports (Including one AC/DC
Powered USB/ eSATA port)
Two USB 2.0 Ports
One eSATA Port (USB 3.0 Port Combined)
One HDMI-Out (1.4a) Port
One DVI-Out Port
One S/PDIF Out Jack
One Headphone/Speaker-Out Jack
One Microphone-In Jack
One Line-In Jack
One Mini-IEEE1394b Port
One RJ-45 LAN Jack
One DC-In Jack
One Display Port
Note: External 7.1CH Audio Output Sup-
ported by Headphone, Microphone, Line-In
and Surround-Out Jacks
Audio
High Definition Audio Compliant Interface
S/PDIF Digital Output
Five Speakers
One Sub Woofer
Built-In Microphone
THX TruStudio Pro
Environmental Spec
Temperature
Operating: 10 ° C - 35 ° C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 20V, 15A (300W)
Removable Polymer Smart Li-Ion 78.44WH
Battery Pack
(Factory Option) Power Converter Box
Dimensions & Weight
419mm (w) * 286mm (d) * 56.5mm -
60.7mm (h)
Around 5.5kg with 1 Video Card, Battery and
ODD
