Figure 1-1: Exterior Features of OMNI-4000
Figure 1-2: Features of the OMNI-4000 Control Panel
Figure 1-3: Switches for Operation and Programming
On/Off Switch
BACKLIGHT Switch
ENTER Switch
MENU Switch
Toxic or Oxygen
Alarm light
Over Range Indicator
Explosive Gas
Alarm Light
Display
General
Alarm Light
Toxic or
oxygen Alarm
Lights
On/Off switch
ENTER switch BACKLIGHT switch
MENU switch
Control Panel
See figure 1-2
Earphone
Socket
Sensor Opening
(one of four)
Removable
Battery Pack
RS232C
Connector
