ENMET Corporation OMNI-4000 S/N 6705 and above
32
Review of Data
This concerns the OMNI-4000 whether connected to a serial printer or the serial port of a compatible personal
computer.
During the printing, the OMNI-4000 automatically chooses one of two displays:
•
If the data storage time is less than 15 minutes, the data is presented in the form of charts, as in Figure 2-24A.
•
If the data storage time is at least 16 minutes, the data is presented in the form of graphs, as in Figure 2-24B.
Figure 2-24A: Data Readout, Chart Figure 2-24B: Data Readout, Graph
Optional Clearing of the Memory
At the end of the printing procedure, the display shows:
The operator has the choice of:
•
Canceling all the data still stored (clear the memory) and just reviewed, prior to putting the OMNI-4000 back
into operation. This choice is implemented by pressing the ENTER switch.
•
Saving the data and putting the OMNI-4000 back into operation. This choice is implemented by pressing the
BACKLIGHT switch.
Return to Normal Mode
This is automatic after pressing a switch, per the above procedure. Remove the printer cable.
Accept: ENTER
Cancel: ¨
To clear
Memory
