2.8 Printing the Histograms
The Histograms function enables printout or transfer to a personal computer of the values and events stored by the
OMNI-4000. This data is stored during the normal operation of the device. Clearing of the information in the memory
can be performed only during the printing procedure.
Connection to a Printer
N
OTE
: This must be PC compatible and fitted with an RS 232C interface configured as follows:
9600 bauds
8 bits
Even parity
1 Stop bit
XON/XOFF protocol
IBM Emulation
The Connecting Cable
This can be supplied as an option. You can also make your own using Figure 2-21. The programming plug, which has
pins 2 and 4 connected, can be used as a part of the connecting cable if desired.
Connections
•
Connect the DIN plug of the connecting cable, shown on the left side of Figure 2-22, to the OMNI-4000.
•
Connect the 25 pin plug of the connecting cable, shown on the right side of Figure 2-22, to the serial port of the
printer.
•
Check the configuration of the switches in the printer and position the switches on the front of this to "ON" and
"ON-LINE." Refer to the printer instruction manual.
Connection to a Compatible Personal Computer
This requires software known as COM4000. Refer to the manual for this software to install it on the PC. The cable is
shown schematically in Figure 2-21.
Review of the Histograms
The histograms can only be reviewed only after the OMNI-4000 has been in operation for at least:
•
Fifteen minutes for printing
•
One minute for display on a PC
Choice of Printing Procedure
•
Connect the cable between the OMNI-4000 and the printer or computer. See Figure 2-23
•
Turn the OMNI-4000 on by pressing the ON/OFF switch
•
Press and release the Menu Selection switch until the display alternately shows:
•
Pressing the ENTER switch starts the printing
•
Pressing any other switch returns the OMNI-4000 to the main menu without altering the data
To print
History
Accept:
ENTER
Cancel: ¨
