Type Bi-Axis inertia controlled Dynamic and Eddy-Current Damping
Dynamic Balance type tone arm
Overall length 306mm. With head shell: max 326 mm
Effective length 241mm (i.e. tonearm pivot point to cartridge stylus point)
Overhang 15mm
Offset angle 21.5 degree
Height 59mm lifts up to 92mm
Height adjustment range 39mm-72mm at sub arm center
Depth 36mm without connecting cable
Optimum cartridge weight 15-35 grams, including headshell
Horizontal tracking angle error -1.1 degree - +2.2 degree ,
0 degree at inner band of record, 2.2 degree at outside
Tracking force adjustment range 0-38 grams by 0.2 grams step
Sensitivity Horizontal less than 50 mg, Vertical less than 40 mg
Net weight 1,380 grams
Output connection DIN 5P connector
Headshell connection EIA standards 4 Pin connector
Accessories low resistance (0.046 ohms/m, 54pF/m) high quality arm cable,
milled aluminum headshell weight 15.4 grams.
mounting template for the arm
overhang gauge for the headshell
8. Specifications
