Specifications - 120
40sx Operator’s Manual
410sx
Centerline plow to outside edge of unit, blade centered (26
x 12-12 tires) 24 in 610 mm
D Maximum cover depth* 24 in 610 mm
Dimensions are based on unit equipped with 26 x 12-12 tires unless otherwise specified.
* Suggested maximum depth. Actual depth will depend on job requirements and soil conditions.
Operation U.S. Metric
Ground drive speeds @ high idle rpm
Maximum transit forward (26 x 12-12 tires) 2.9 mph 4.6 km/h
Maximum transit forward (23 x 10.50-12 tires) 2.5 mph 4.0 km/h
Maximum transit reverse (26 x 12-12 tires) 1.5 mph 2.5 km/h
Maximum transit reverse (23 x 10.50-12 tires) 1.3 mph 2.1 km/h
Maximum pipe or cable diameter, pull type plow blade 3 in 75 mm
Vehicle clearance circle, wall-to-wall, with trenching attachment and 18” (457 mm) plow blade
Right turn (26 x 12-12 tires) 21 ft 6.4 m
Right turn (23 x 10.50-12 tires) 20 ft 6.1 m
Left turn (26 x 12-12 tires) 19 ft 5.8 m
Left turn (23 x 10.50-12 tires) 18 ft 5.5 m
Operating weight
Basic unit weight with 18” (46 cm) plow blade and
H400 with 36” (91 cm) boom and cup tooth chain 3610 lb 1632 kg
Power U.S. Metric
Engine: Kubota WG1605-G-E3 liquid-cooled four cylinder with electronic governor
Fuel: unleaded gasoline
Displacement 93.79 cu in 1.537 L
Bore 3.11 in 79 mm
Stroke 3.09 in 78.4 mm
Engine manufacturer’s gross power rating @ 3600 rpm (SAE J1995) 49.6 hp 37kW
Estimated net power rating @ 3600 rpm (SAE J1349) 47.6 hp 35.5 kW
