Specifications - 102
FX25 Operator’s Manual
500
CMW
T9S Trailer U.S. Metric
Dimensions
Clearance (at jack foot pad) 12 in 305 mm
Adj. coupler height 18-24 in 457-610 mm
Width between fenders 76 in 1.9 m
Width outside fenders 96 in 2.4 m
General
Number of axles 2
Coupler (square mount drawbar) 3 in or 2.5 in 76 mm or 64
mm
Type of brakes electric or hydraulic surge
Lug nut torque 90-120 ft•lb 122-163 N•m
Hitch bolt torque 160 ft•lb 217 N•m
Electrical system 12V DC
Tire ST235/85R16 load range E 80 psi 5.5 bar
Load rating
Tongue weight (empty water, empty vac) 1350 lb 612 kg
Tongue weight (full water, empty vac) 1500 lb 680 kg
Tongue weight (full vac, empty water) 1218 lb 552 kg
GVWR (gross vehicle weight rating) 9950 lb 4513 kg
GAWR (gross axle weight rating, each) 6000 lb 2722 kg
Load ratings for speeds up to 65 mph (104 km/h).
