FX25 Operator’s Manual
Specifications - 101
500
CMW
Vacuum system U.S. Metric
Tank capacity 500 gal 1893 L
Drive type belt
Displacement 543 cfm
15.3 m
3
/min
Maximum vacuum 15 in Hg 381 mm Hg
Vacuum tank door diameter 52 in 1.3 m
Drain valve size 6 in 152 mm
Inlet valve size 4 in 102 mm
Primary shutoff valve size (ball type) 12 in 305 mm
Filter type washable polyester
Filter area
100 ft
2
9.3 m
2
Suction hose size 3 in 76 mm
Suction hose length (total) 30 ft 9.1 m
Water pump system U.S. Metric
Maximum pressure 3000 psi 207 bar
Flow 4 gpm 15.1 L/min
Hose reel capacity (locking) 50 ft 15.3 m
Antifreeze 50/50 water/antifreeze mix
Clutch type electric with auto de-clutch
Fluid capacities U.S. Metric
Engine oil with filter 4.2 qt 4 L
Fuel tank 6.9 gal 26.1 L
Vacuum pump 1.5 qt 1.4 L
Hydraulic reservoir 6.0 gal 22.7 L
Water pump 41 oz 1.2 L
Water tank 80 gal 303 L
