FX25 Operator’s Manual
Specifications - 99
500
CMW
Specifications
500
Dimensions U.S. Metric
L Length, T9S or T9SH trailer 200 in 5.1 m
H Height 86 in 2.3 m
W Width 96 in 2.2 m
Weight: suction only unit
Dry 4805 lb 2180 kg
Full 8870 lb 4023 kg
Weight: suction and water unit
Dry 4930 lb 2236 kg
Full water tank, empty vac tank 5665 lb 2570 kg
Empty water tank, full vac tank 9120 lb 4137 kg
Full water tank, full vac tank 9765 lb 4430 kg
NOTICE: Do not transport vac system and T9S, T9SH trailer with full water tank and full vac tank. Doing
so will exceed the trailer’s rated Gross Motor Vehicle Weight.
LL W W
H H
j32om032h.eps j32om032h.eps
