Multi format imager installation – Da-Lite Multi Format Imager User Manual
Page 12
12
Multi Format Imager Installation
7. Hang the frame assembly on the hanger brackets as shown in Figure 22. Be careful as bracket is to slide in front of the aluminum
guide channel. There is a lip on the back of the frame that wedges itself in to the hanger bracket once fully installed on bracket.
This is a two person installation. Do not attempt to do this without two people.
Figure 22
Figure 23
Figure 24
Slide Frame Over
Hanger Brackets
Back Lip Of Frame
Will Wedge Down
Between Wall
Bracket And Wall
Bracket
