11

Installation

Corinex AV200 Powerline Ethernet Wall Mount

2.6

Connecting the Wall Mount Adapter

To connect the Corinex AV200 Powerline Ethernet Wall Mount to your computer,
follow the steps listed below.

1. Once the security configuration and synchronization have been completed

the adapters may be unplugged and taken to the respective places in the home

where the computers will be connected to them.
2. Connect the supplied Ethernet cable to the Ethernet (LAN) port on the wall
mount, and to an Ethernet port on your computer.
3.

Plug

the

Corinex AV200 Powerline Ethernet Wall Mount unit directly

into any standard electrical outlet.

Note: The Corinex AV200 Powerline Ethernet Wall Mount should be plugged
directly into a wall outlet, not into a power strip or surge suppressor. Power
strips and surge suppressors can weaken or block the Powerline network
signal.

2.5 Technical

Specifications

Standards Compliance IEEE

802.3u

Speed

Up to 200 Mbps on physical layer

AC Plug Type

US, EU, UK and AUS

LED Status Lights

PWR, VPI, AP

Schnittstellen

10/100BaseT Fast Ethernet, Powerline

BenutzterFrequenzbereich

2 – 34 MHz

Eingangsleistung

85 to 265 V AC, 50/60 Hz

Abmessungen

107 mm L x 72 mm B x 79 mm H

Übertragene Stromspektrumdichte -56 dBm/Hz
Stromverbrauch

5W

Sicherheit & EMI

UL/EN 60950, FCC Teil 15, EN 55022
EMC Limits
