Installation
Corinex AV200 Powerline Ethernet Wall Mount
10
2.4.3 LED Definitions
2.4.3.1 VPI LED
VPI
Colour
Adapter Status
Meaning
Low Red
OFF (Standby)
Adapter is in Standby mode
Red
ON
If Powerline link, Estimated application
Throughput < Low Threshold
Orange
ON
If Powerline link, Low Threshold < Esti-
mated application Throughput < High
Threshold
Green
ON
If Powerline link, Estimated application-
Throughput > High Threshold
Blinking
ON
Adapter has Ethernet link activity
The low and high throughput thresholds are default to be 6 Mbps and 12 Mbps
respectively, and can be redefined by users through the web interface.
2.4.3.2 AP LED
When the adapter is configured as Fixed AP, the LED will be on. When the adapter
is configured as EP, the LED will be off.
